Dahua XVR7416L User Manual

94
Model
Parameters
HCVR7104H-4M
HCVR7108H-4M
HCVR7116H-4M
Encode
Resolution
Main stream:
2K(2560*1440)@15f/1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF
Sub stream: D1/CIF/QCIF
Video Frame Rate
2K resolution: PAL:1~15f/s；NTSC：1~15f/s
Other resolutions: PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
32Kbps-6144Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps.
For 1080N: default setup is 4Mbps，max supports 6Mbps.
For 2K: non realtime default setup is 4Mbps，max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI/CVBS)
8-ch BNC port
(HDCVI/CVBS)
16-ch BNC port
(HDCVI/CVBS)
Network Video
Input
 Max add 2 IP
channel
connection.
 Analog
/digital channel
switch. Max 6 IP
channel
connections
 Connection
bandwidth:8Mbp
s-24Mbps
 Max add 4 IP
channel
connection.
 Analog
/digital channel
switch. Max 12
IP channel
connections
 Connection
bandwidth:16
Mbps-48Mbps
 Max add 8 IP
channel
connection.
 Analog
/digital channel
switch. Max 24 IP
channel
connections
 Connection
bandwidth:32Mbps-
96Mbps
Video Output
1-channel VGA output，
1-channel HDMI output, max 4K(3840*2160)@30f
HDMI/ VGA video output at the same time (of the same video source
or different video source).
Loop Output
N/A
Matrix Output
When the HDMI and VGA are of different video output, system
supports one matrix output.
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional Talk
Input
Reuse the audio input/output port
Record
Record Mode
Schedule record/manual record/MD record/Alarm record/intelligent
