Dahua XVR7416L User Manual

200
SN
Icon
Name
Note
playback.
7
MIC IN
Audio input port
Bidirectional talk input port. It
is to receive the analog audio
signal output from the devices
such as mike phone, pickup.
8
AUDIO IN
Audio input port
It is to receive the analog
audio signal output from the
devices such as mike phone,
pickup.
9
VIDEO IN
Video input port
Connect to analog camera to
input video signal.
10
Network port
1000M Ethernet port
11
VGA
VGA video output port
VGA video output port.
Output analog video signal. It
can connect to the monitor to
view analog video.
12
HDMI
High Definition Media
Interface
High definition audio and
video signal output port. It
transmits uncompressed high
definition video and
multiple-channel data to the
HDMI port of the display
device.
13
eSATA
eSATA port
External SATA port. It can
connect to the device of the
SATA port. Please jump the
HDD when there is peripheral
connected HDD.
14
USB2.0 port
USB2.0 port. Connect to
mouse, USB storage device,
USB burner and etc.
15
Power socket
Power socket
16
GND
GND
2.2.32 HCVR42XXL-S2 Series
The rear panel is shown as in Figure 2-78
