If you enabled this function, System can send out an email to alert you
when an alarm occurs.
Check the box here to enable this function. The buzzer beeps when an
alarm occurs.
Check the box here, system can record the network event alarm log.
5.8.3.6 Alarm Output
It is to set alarm output mode. See Figure 5-82.
Figure 5-82
5.8.4 Storage
5.8.4.1 Schedule
5.8.4.1.1 Schedule Record
In this interfaces, you can add or remove the schedule record setup. See Figure 5-83.
There are three record modes: general (auto), motion detect and alarm. There are six
periods in one day.
You can view the current time period setup from the color bar.
Green color stands for the general record/snapshot.
Yellow color stands for the motion detect record/snapshot..
Red color stands for the alarm record/snapshot.
Blue color stands for MD&alarm record/snapshot.
