Dahua XVR7416L User Manual

132
1.3.73 XVR74XXL Series
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Card number record, mark record, alarm record, motion detection
record, regular record, manual record, intelligent record.
Playback Mode
Instant playback, normal playback, event playback, mark playback,
intelligent playback(human face, motion detection)
Record
Playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-channel
16-channel
Alarm Output
6-channel
HDD
HDD Port
4 SATA ports. Support eSATA port.
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports(One at
the front panel and
two at the rear
panel)
3 USB ports (One at the front panel and two
at the rear panel. The rear panel supports
USB3.0)
Other
Power
AC100-240V 1.9A 50/60Hz
Power
Consumption
（No HDD）
30W (No HDD)
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case，440mm（W）×410mm（D）×70mm（H）
Weight
（No HDD）
≤7KG (No HDD)
≤7.2KG (No HDD)
≤7.5KG (No HDD)
Installation
Mode
Desk installation
Model
Parameters
XVR7408L
XVR7416L
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264H, H.264, H.264B
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s

Dahua XVR7416L Specifications

General

Brand	Dahua
Model	XVR7416L
Category	DVR
Language	English
