Dahua XVR7416L User Manual

130
1.3.72 XVR54XXL Series
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
Communication
Port
Network
1 RJ45 port,
100Mbps Ethernet
port
1 RJ45 port, 1000Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One
at the front panel
and one at the rear
panel)
1 USB2.0 port and 1 USB3.0 port (One
USB2.0 port at the front panel and one
USB3.0 port at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤8W
≤10W
≤15W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimension
1U case，375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
Model
Parameters
XVR5408L
XVR5416L
XVR5432L
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264H, H.264, H.264B
Encode
Resolution
1080P@15fps/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
