Dahua XVR7416L User Manual

264
Figure 4-31
4.6.1 Main Menu
Click button to go to the main menu interface.
4.6.2 Output Screen
Select corresponding window-split mode and output channels.
4.6.3 Previous/Next Screen
Click to go to the previous screen, click to go to the next screen. For
example, if you are using 4-split mode, the first screen is displaying the channel 1-4,
click , you can view channel 5-8.
4.6.4 Tour
Click button to enable tour, the icon becomes , you can see the tour is in
process.
4.6.5 Favorites
Click , system pops up add/edit favorites. See Figure 4-32.
Figure 4-32
4.6.6 Channel
It is to pop up channel tree. You can left click to select a channel on the tree and then drag
it to the preview window on the left pane.
4.6.7 PTZ
Click , system goes to the PTZ control interface. Please refer to chapter 4.5.3.
4.6.8 Color
Click button , system goes to the color interface. Please refer to chapter 4.5.5.
4.6.9 Search
Click button , system goes to search interface. Please refer to chapter 4.9.1
4.6.10 Alarm Status
