Dahua XVR7416L User Manual

210
SN
Icon
Name
Note
output.
12V
+12V power output
port
+12V power output port. It can
provide the power to some
peripheral devices such as the
camera or the alarm device. Please
note the supplying power shall be
below 1A.
G
Ground
Ground
9
RS-232
RS232 debug COM.
It is for general COM debug to
configure IP address or transfer
transparent COM data.
10
USB port
Connect to USB storage device,
mouse, burning DVD-ROM and etc.
11
eSATA
eSATA port
External SATA port. It can connect
to the device of the SATA port.
Please make sure there is power
supplying when there is peripheral
connected HDD.
12
HDMI 1
High Definition
Media Interface
High definition audio and video
signal output port. It transmits
uncompressed high definition video
and multiple-channel data to the
HDMI port of the display device.
13
VGA
VGA video output
port
VGA video output port. Output
analog video signal. Can connect to
the monitor to view ananlog video
output.
14
Network port
1000Mbps Ethernet port
15
VIDEO IN
Video input port
Connect to analog camera, video
input signal.
The XVR5416L/XVR7408L/XVR7416L rear panel is shown as below. See Figure 2-84.
