Typical Wiring Mistakes Si-95
148 Appendix
The indoor-to-
outdoor terminal of
outdoor unit 1 and
the outdoor-to-
outdoor terminal of
outdoor unit 2 are
connected
The indoor-to-
outdoor terminals
of outdoor units 1
and 2 are
connected
Indoor unit 1 Normal
Indoor unit 2 Normal
Indoor unit 3
UH malfunction
Indoor unit 4
Indoor unit 1
UH malfunction
Indoor unit 2
Indoor unit 3
Indoor unit 4
