Daikin VRV K - 1.12 Pump Down Residual Operation

Functions Si-95
16 Functions Inverter K Series
Heat exchanger mode
COND: Condenser
EVAP: Evaporator
Heat exchanger 1 Heat exchanger 2 FAN EV mode
Cooling operation
↑



















↓
Heat operation
COND COND H + ON 1
COND COND L + ON 1
COND COND H + OFF 1
COND COND L + OFF 1
COND EVAP H + ON 2
COND EVAP L + ON 2
COND EVAP H + OFF 2
COND EVAP L + OFF 2
COND EVAP L + OFF 3
COND EVAP L + OFF 4
COND EVAP H + OFF 4
COND EVAP H + ON 4
EVAP EVAP L + OFF 4
EVAP EVAP H + OFF 4
EVAP EVAP H + ON 4
EVAP EVAP H + ON 5
