Test Operation Si-95
44 Test Operation Inverter K Series
1 Service monitor <HAP>
(Green)
Normal ................ licker
Malfunction ......... On or off
2 Function setting switch or LED
LED display
8 : On
9 : Flicker
7 : Off
Mode button ......... Mode change
• Set return button .......... Changes or enters address or data.
• Wiring check button .... Push and hold for 5 sec. to start wiring check.
• Reset button ................. Push and hold for 5 sec. if the indoor unit’s PC board has been replaced, or
there has been a change in the combination of indoor and outdoor units, such as indoor unit extension,
etc.
3 Jumper pin Forced defrost operation by short circuit.
Setting mode 1
(H1P off)
Push 1 time.
Monitor mode
(H1P flickers)
Push 1 time.
Push and hold for 5 sec.
Setting mode 2
(H1P on)
Push 1 time.
(VF014)
■ ■
BLUE
M
D
S
X26A
(VL015)
