DF4510HD | DF4910HD | DDF4510HDV-IM/-SM | DDF4910HDV-IM/-SM
www.dallmeier.com 29
Step 3
 Tighten the M4 locking screw (Fig. 5-4) of both ceiling clamps with a Phillips screw-
driver until the housing is xed (Fig. 6-5).
Ceiling clamp Ceiling clamp
Suspended ceiling
Phillips screwdriver
Fig. 6-4
Locked ceiling clampLocked ceiling clamp
Suspended ceiling
Fig. 6-5
