Danfoss AK-CC55 Multi Coil User Manual

Function
Values
R-W
Code
1
2
3
4
5
Min. value
Max. value
Fact. value
Def. start 5 - min
1-2
t15
*
*
*
*
*
0 min
59 min
0 min
Def. start 6 - Hours
1-2
t06
*
*
*
*
*
0 hours
23 hours
0 hour
Def. start 6 - min
1-2
t16
*
*
*
*
*
0 min
59 min
0 min
Time hours
0-1
t07
*
*
*
*
*
0 hours
23 hours
0 hour
Time min
0-1
t08
*
*
*
*
*
0 min
59 min
0 min
Time date
0-1
t45
*
*
*
*
*
1
31
1
Time month
0-1
t46
*
*
*
*
*
1
12
1
Time year
0-1
t47
*
*
*
*
*
0
100
0
Monday - Follow schedule
0=No, 1=Yes
1-2
t51
*
*
*
*
*
0
1
1
Tuesday - Follow schedule
0=No, 1=Yes
1-2
t52
*
*
*
*
*
0
1
1
Wednesday - Follow schedule
0=No, 1=Yes
1-2
t53
*
*
*
*
*
0
1
1
Thursday - Follow schedule
0=No, 1=Yes
1-2
t54
*
*
*
*
*
0
1
1
Friday - Follow schedule
0=No, 1=Yes
1-2
t55
*
*
*
*
*
0
1
1
Saturday - Follow schedule
0=No, 1=Yes
1-2
t56
*
*
*
*
*
0
1
1
Sunday - Follow schedule
0=No, 1=Yes
1-2
t57
*
*
*
*
*
0
1
1
Humidity control
Table 20: Humidity control
Function
Values
R-W
Code
1
2
3
4
5
Min. value
Max. value
Fact. value
Humidity cut-in
0-2
h23
*
0 %
100 %
70%
Humidity dierential
1-2
h24
*
1 %
30 %
5%
Humidity high alarm limit
1-2
h25
*
0 %
100 %
100%
Humidity low alarm limit
1-2
h26
*
0 %
100 %
0%
Humidity alarm delay
1-2
h27
*
0 min
240 min
60 min
Humidity ctrl. at defrost
0=No, 1=Yes
1-2
h28
*
0
1
0
Humidity sensor - Min signal
1-2
(1)
h29
*
0 %
h30
0%
Humidity sensor - Max signal
1-2
(1)
h30
*
h29
100 %
100%
Humidity control
0=None, 1=Humidier, 2=Dehu-
midier
1-2
(1)
h31
*
0
2
0
Humidity max. temp.
1-2
h32
*
h33
70.0 °C
70.0 °C
Humidity min. temp.
1-2
h33
*
-5.0 °C
h32
2.0 °C
(1)
In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF.
(1)
In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF.
Miscellaneous
Table 21: Miscellaneous
Function
Values
R-W
Code
1
2
3
4
5
Min. value
Max. value
Fact. value
Delay of outputs at pow-
er-up
1-2
o01
*
*
*
*
*
0 s
600 s
5s
DI1
Conguration
0=None, 1=DI status, 2=Door function,
3=Door alarm, 4=Defrost start, 5=Main
switch, 6=Night setback, 7=Thermostat
band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced
cooling, 14=Forced closing, 15=Shut-
down, 16=Light control, 20=Leak detec-
tion, 21=Adaptive liquid control,
29=Door fan stop
1-2
(1)
o02
*
*
0
29
0
Network address
1-3
(1)
o03
*
*
*
*
*
0
240
0
Service pin
0=OFF, 1=ON
1-2
o04
*
*
*
*
*
0
1
0
Access code 3
3-3
o05
*
*
*
*
*
0
999
0
Temperature sensor type
0=Pt 1000, 1=PTC 1000, 2=NTC 5k,
3=NTC 10k, 4=User-dened
1-3
(1)
o06
*
*
*
*
*
0
4
0
Max. hold time
1-2
o16
*
*
*
*
*
0 min
360 min
20 min
Pe Min range
1-3
(1)
o20
*
*
*
*
*
-1.0 Bar
5.0 Bar
-1.0Bar
Pe Max range
1-3
(1)
o21
*
*
*
*
*
6.0 Bar
200.0 Bar
12.0Bar
© Danfoss | Climate Solutions | 2022.08 BC365022028193en-000201 | 35
AK-CC55 Multi Coil
