Danfoss AK-CC55 Multi Coil User Manual

(1)
In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF.
(2)
In order to change this parameter the parameter r12 Main switch must be set in position "SEr" allowing manual control of outputs.
(1)
In order to change this parameter the regulation must be stopped via the parameter r12 Main switch = OFF.
(2)
In order to change this parameter the parameter r12 Main switch must be set in position "SEr" allowing manual control of outputs.
Service
Table 24: Service
Function
Values
R-W
Code
1
2
3
4
5
Min. value
Max. value
Fact. value
Control state A
0=Normal ctrl., 1=Hold after defrost,
4=Drip o, 10=Main switch OFF,
11=Thermostat cutout, 12=Frost pro-
tection S4, 14=Defrost, 15=Fan delay,
16=Forced closing, 17=Door open,
18=Melt period, 19=Modulating temp.
control, 20=Emergency control,
23=Adaptive superheat control,
24=Start injection, 25=Manual control,
26=No refrigerant selected, 29=Case
cleaning, 30=Forced cooling, 31=Door
open, 32=Power-up delay, 33=Air heat-
ing, 45=Shut down controller, 48=Adap-
tive liquid control
0-X
u00
*
*
*
*
*
0
48
0
S5 Evaporator A
0-X
u09
*
*
*
-200.0 °C
200.0 °C
0.0 °C
DI1 Status
0=OFF, 1=ON
0-X
u10
*
*
0
1
0
Defrost time A
0-X
u11
*
*
*
*
*
0 min
900 min
0 min
Night condition
0=OFF, 1=ON
0-X
u13
*
*
*
*
*
0
1
0
S4 Air OFF evap. A
0-X
u16
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat air temp. A
0-X
u17
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat run time A
0-X
u18
*
*
*
*
*
0 min
999 min
0 min
S2 Gas outlet A
0-X
u20
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Superheat A
0-X
u21
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Superheat reference A
0-X
u22
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
EEV opening A
0-X
u23
*
*
*
*
*
0 %
100 %
0%
Pe Evap. pressure
0-X
u25
*
*
*
*
*
-1.0 Bar
200.0 Bar
0.0Bar
Te Evap. temp.
0-X
u26
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
DI2 Status
0=OFF, 1=ON
0-X
u37
*
*
*
*
*
0
1
0
Display readout 1
0-X
u56
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Alarm air temp. A
0-X
u57
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Fan
0=OFF, 1=ON
0-X
u59
*
*
*
*
*
0
1
0
Defrost A
0=OFF, 1=ON
0-X
u60
*
*
*
0
1
0
Rail heat
0=OFF, 1=ON
0-X
u61
*
*
*
0
1
0
Alarm relay
0=OFF, 1=ON
0-X
u62
*
*
*
*
0
1
0
Light
0=OFF, 1=ON
0-X
u63
*
*
*
*
*
0
1
0
S5 Evaporator B
0-X
u75
*
*
-200.0 °C
200.0 °C
0.0 °C
Defrost B
0=OFF, 1=ON
0-X
u83
*
*
0
1
0
Air heater
0=OFF, 1=ON
0-X
u84
*
0
1
0
Rail heat power
0-X
u85
*
*
*
*
*
0 %
100 %
0%
Thermostat band
1=Band 1, 2=Band 2
0-X
u86
*
*
*
*
*
1
2
1
DI3 Status
0=OFF, 1=ON
0-X
u87
*
*
*
*
*
0
1
0
Thermostat cut-in temp.
0-X
u90
*
*
*
*
*
-200.0 °C
200.0 °C
4.0 °C
Thermostat cut-out
temp.
0-X
u91
*
*
*
*
*
-200.0 °C
200.0 °C
2.0 °C
Alarm air temp. B
0-X
U34
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Display readout 2
0-X
U35
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Network status
0-X
U45
*
*
*
*
*
0 %
100 %
0%
Humidity sensor
0-X
U57
*
0 %
100 %
0%
Humidier
0=OFF, 1=ON
0-X
U58
*
0
1
0
Rail heat PWM
0-X
U59
*
*
*
*
*
0 %
100 %
0%
Food temperature A
0-X
U72
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Defrost sensor tempera-
ture A
0-X
U73
*
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
AK-CC55 Multi Coil
© Danfoss | Climate Solutions | 2022.08 BC365022028193en-000201 | 38
