AK-CC55 connect menu (SW ver. 1.9x)
Start / Stop
Table 25: Start / Stop
Start / stop of refrigeration.
With this setting refrigeration can be started, stopped
or a manual override of the outputs can be allowed.
(For manual control the value is set at -1). Then the
outputs can be force controlled. Start / stop of refrig-
eration can also be accomplished with the external
switch function connected to a DI input.Stopped con-
trol will give a ”Main switch OFF" alarm.
-1=Manual, 0=Stop, 1=Start
Delay of outputs at
power-up
Delay of output signal after start-up.
After start-up or a power failure the controller’s func-
tions can be delayed so that overloading of the elec-
tricity supply network is avoided. Here you can set the
time delay.
Conguration
Table 26: Conguration
Start / stop of refrigeration.
With this setting refrigeration can be started, stopped
or a manual override of the outputs can be allowed.
(For manual control the value is set at -1). Then the
outputs can be force controlled. Start / stop of refrig-
eration can also be accomplished with the external
switch function connected to a DI input. Stopped
control will give a ”Main switch OFF" alarm.
-1=Manual, 0=Stop, 1=Start
Selection of application.
The controller covers several applications for control
of a refrigerated case. Here you set which of the possi-
ble applications is required.This menu can only be set
when regulation is stopped, i.e. “r12 Main Switch” is
set to 0.
1=1. One evaporator MT/LT
2=2. Two evaporators MT/LT
3=3. Three evaporators MT
4=4. Coldroom 2 MT/HT
5=5. Coldroom 2 MT/LT
Select the function of the analogue output
Select the function of the digital input
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
14=Forced closing, 15=Shutdown, 16=Light control,
20=Leak detection, 21=Adaptive liquid control,
29=Door fan stop
Select the function of the digital input
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling, 13=Co-
ordinated defrost, 14=Forced closing, 15=Shutdown,
16=Light control, 20=Leak detection, 21=Adaptive
liquid control, 29=Door fan stop
Select the function of the digital input
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
14=Forced closing, 15=Shutdown, 16=Light control,
20=Leak detection, 21=Adaptive liquid control,
29=Door fan stop
Select the type of refrigerant.
If the required refrigerant is not part of the list, the
user dened option can be used. Please contact Dan-
foss for detailed information
WARNING:
Wrong selection of refrigerant may cause damage to
the system.
0=Not seleted, 6=R13, 7=R13b1, 2=R22, 8=R23,
14=R32, 11=R114, 3=R134a, 12=R142b, 24=R170,
15=R227, 25=R290, 16=R401A, 18=R402A, 19=R404A,
21=R407A, 22=R407B, 20=R407C, 37=R407F,
49=R407H, 23=R410A, 32=R413A, 30=R417A,
31=R422A, 33=R422D, 34=R427A, 35=R438A,
40=R448A, 41=R449A, 48=R449B, 43=R450A,
44=R452B, 45=R454B, 9=R500, 4=R502, 10=R503,
17=R507, 36=R513A, 26=R600, 27=R600a, 5=R717,
28=R744, 46=R1233zdE, 38=R1234ze, 39=R1234yf,
47=R1234zeZ, 29=R1270, 42=R452A, 1=User dened
display, 13=User dened
Refrigerant factor for a custom refrigerant - please
contact Danfoss for detailed information
© Danfoss | Climate Solutions | 2022.08 BC365022028193en-000201 | 41
