Danfoss AK-CC55 Multi Coil User Manual

1.
2.
3.
Figure 46: Connect to controller Figure 47: Controller dashboard Figure 48: Set-up menu
Operation via AK-UI55 Bluetooth
Access to parameters via Bluetooth and app
App can be downloaded from App Store and Google Play.
◦ Name = AK-CC55 Connect
◦ Start the app.
Click on the display’s Bluetooth button for 3 seconds.
◦ The Bluetooth light will then ash while display is showing the controller’s address.
Connect to the controller from the app.
Figure 45: AK-UI55 Bluetooth
Display info:
• Loc
• The operation is locked and cannot be operated via Bluetooth.
• Unlock from the system manager.
The functions are described on Page 41 – Page 58.
AK-CC55 Multi Coil
© Danfoss | Climate Solutions | 2022.08 BC365022028193en-000201 | 40
