Danfoss AK-CC55 Multi Coil User Manual

Function
Values
R-W
Code
1
2
3
4
5
Min. value
Max. value
Fact. value
Control state B
0=Normal ctrl., 1=Hold after defrost,
4=Drip o, 10=Main switch OFF,
11=Thermostat cutout, 12=Frost pro-
tection S4, 13=Not_used, 14=Defrost,
15=Fan delay, 16=Forced closing,
17=Door open, 18=Melt period,
19=Modulating temp. control,
20=Emergency control, 23=Adaptive
superheat control, 24=Start injection,
25=Manual control, 26=No refrigerant
selected, 29=Case cleaning, 30=Forced
cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down
controller, 48=Adaptive liquid control
0-X
U74
*
*
*
*
0
48
0
Defrost time B
0-X
U75
*
*
*
*
0 min
900 min
0 min
S4 Air OFF evap. B
0-X
U76
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat air temp. B
0-X
U77
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat run time B
0-X
U78
*
*
*
*
0 min
999 min
0 min
S2 Gas outlet B
0-X
U79
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Superheat B
0-X
U80
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Superheat reference B
0-X
U81
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
EEV opening B
0-X
U82
*
*
*
*
0 %
100 %
0%
Control state C
0=Normal ctrl., 1=Hold after defrost,
4=Drip o, 10=Main switch OFF,
11=Thermostat cutout, 12=Frost pro-
tection S4, 13=Not_used, 14=Defrost,
15=Fan delay, 16=Forced closing,
17=Door open, 18=Melt period,
19=Modulating temp. control,
20=Emergency control, 23=Adaptive
superheat control, 24=Start injection,
25=Manual control, 26=No refrigerant
selected, 29=Case cleaning, 30=Forced
cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down
controller, 48=Adaptive liquid control
0-X
U83
*
0
48
0
Defrost time C
0-X
U84
*
0 min
900 min
0 min
S4 Air OFF evap. C
0-X
U85
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat air temp. C
0-X
U86
*
-200.0 °C
200.0 °C
0.0 °C
Thermostat run time C
0-X
U87
*
0 min
999 min
0 min
S2 Gas outlet C
0-X
U88
*
-200.0 °C
200.0 °C
0.0 °C
Superheat C
0-X
U89
*
-200.0 °C
200.0 °C
0.0 °C
Superheat reference C
0-X
U90
*
-200.0 °C
200.0 °C
0.0 °C
EEV opening C
0-X
U91
*
0 %
100 %
0%
Alarm air temp. C
0-X
U92
*
-200.0 °C
200.0 °C
0.0 °C
Defrost sensor tempera-
ture B
0-X
U93
*
*
*
*
-200.0 °C
200.0 °C
0.0 °C
Defrost sensor tempera-
ture C
0-X
U94
*
-200.0 °C
200.0 °C
0.0 °C
Dehumidier
0=OFF, 1=ON
0-X
U96
*
0
1
0
© Danfoss | Climate Solutions | 2022.08 BC365022028193en-000201 | 39
