10 Start up
NOTE! Read the safety instructions!
⚠
The installation may only be commissioned if the heating
system, water heater and brine system have been filled and
bled. Otherwise the circulation pumps may be damaged.
⚠
If the installation is only to be run on auxiliary heating, first
ensure that the heating system is filled and bled and that nei-
ther the brine pump nor the compressor can be started. This
is carried out by setting the operating mode to ADD.HEAT.
⚠
Any alarms that may occur in connection with the installation
can be fault-traced in the “Troubleshooting” section in the
service instructions.
For
⚠
DHP-H Opti Pro SP (Single Phase) heat pumps it is imper-
ative that the maximum hot water temperature is altered
from the default factory setting from 95°C to 85°C. Refer to
Chapter 14.2 menu Service – HGW Parameter MAX TEMP.
10.1 Installation checklist
Before manual test operation check the following points:
Piping installation, heating system
• Pipeconnectionsinaccordancewiththeconnectiondiagram
• Flexiblehosesonthesupplyandreturnlines
• Pipeinsulation
• Straineronreturnline,heatingsystem
• Bleedingoftheheatingsystem
• Allradiatorvalvesfullyopen
• Expansiontankheatingsystem(notincludedinthedelivery)
• Safetyvalveforexpansiontank(notincludedinthedelivery)
• Fillercockheatingsystem(notincludedinthedelivery)
• Leakageinspection
If a an external water heater is installed, also check:
• Exchangevalve
• Safetyvalveforcoldwater(9bar)
Electrical Installation
• Circuit-breaker
• Fuseprotection
• Directionofrotationofthecompressor
• Coolantpump
• AtDHP-A,-AL,outdoorunit
• AtDHP-A,-AL,defrostersensor
• Positioningoftheoutdoorsensor
• Controlcomputersettings
If a an external water heater is installed, also check:
• Exchangevalve
Brine system
• Expansion/bleedtankonbrinein
• Safetyvalveforexpansiontank
• Fillerconnectoronbrinein
• Insulationintheoutsidewalllead-in
• Otherbrinepipeinsulation
• Bleedingofbrinesystem
• Leakageinspection
10.2 Manual test
Test operate and at the same time check the function of the tested
components.
Activate MANUAL TEST
1. Ensure that the main circuit breaker is on.
2. Select operating mode
, in the menu INFORMATION ->
OPERAT.->
3. Open the SERVICE menu by holding
in for five seconds.
4. Set the value for MANUAL TEST to 2.
⚠
NOTE! Select position 2 to navigate away from the MANUAL
TEST menu during ongoing test operation!
Test the brine pump
5. Start the brine system’s brine pump by setting the value
BRINEPUMP to 1.
6. Check that the brine pump is running by:
• listening
• puttingahandonthepump
• checkingthatthelevelintheexpansiontankisstable.Ifthelevel
is not stable there is air in the system.
• listenforair
7. If the pump does not start see the section, “Starting circulation
pumps manually”.
8. If there is air in the brine system, bleed according to section,
“Bleeding the brine system”.
9. Stop the brine pump by setting the value to 0.
Test the circulation pump
10. Start the heating system circulation pump by setting the value
CIRC.PUMP to 1.
11. Check that the circulation pump is running by:
• listening
• puttingahandonthepump
• listenforair
12. If the pump does not start see the section, “Starting circulation
pumps manually”.
13. If there is air in the heating system, bleed according to section,
“Bleeding the heating system”.
14. Stop the circulation pump by setting the value to 0.
Test the exchange valve
15. Activate the 3-way valve by setting the value VXV WARMWATER
to 1.
16. Check that the arm on the 3-way valve changes position.
17. If the arm does not change position, see the “Troubleshooting”
section in the service instructions.
Test the compressor
18. Start the circulation pump by setting the value CIRC.PUMP to 1
19. Start the heat pump compressor by setting the value
HEATPUMP to 1. At the same time as the value is set to 1 for
HEAT PUMP the brine pump also starts.
⚠
NOTE! Risk of burns, the delivery line on the compressor can
reach 70-80°C!
