Danfoss MCX08M User Manual

Danfoss Electronics spa
Air Handling seq.- user manual
DKRCC.PS.RI.A1.02 / 520H4358 - Air Handling Seq. user manual - V 2.2
Produced by Danfoss Electronics spa Graphic Department, 10-2009
15
ANALOG OUTPUTS
Code (LED and LCD) Description (LCD) Function
SUF Supply Fan Supply Fan control
REF Return Fan Return Fan control
RDA Mixing damper Mixing damper control
EDA External Damper External damper control
HUA Humidier Humidier control
bA1 Valve1 Valve 1 control
bA2 Valve2 Valve 2 control
bA3 Valve3 Valve 3 control
DHU Dehumidier Dehumidier control
ERA Recovery Energy recovery control
Tab 8_ [Conguring the AHU software - Analog Outputs]
DIGITAL OUTPUTS
Code (LED and LCD) Description (LCD) Function
ALA Alarm Alarm
WAR Warning Warning
SUF Supply Fan Supply Fan control
REF Return Fan Return Fan control
RDD Mixing Damper Mixing Damper control
EDD External Damper External Damper control
SFL SupplyFanLow Low Supply Fan speed
SFH SupplyFanHigh High Supply Fan speed
RFL ReturnFanLow Low Return Fan speed
RFH ReturnFanHigh High Return Fan speed
dEU Dehumidier External dehumidier control
HUM Humidier External humidier control
HUP HumidPump Humidier pump control
ERD Recovery Energy recovery control
ERP Recovery Pump Energy recovery pump control
b1 Valve1ONOFF Controls the ON/OFF valve of coil 1
b1O Valve1Open Controls opening of 3-point valve of coil 1
b1C Valve1Close Controls closing of 3-point valve of coil 1
b11 Coil1Step1 Controls step 1 of coil 1
b12 Coil1Step2 Controls step 2 of coil 1
b13 Coil1Step3 Controls step 3 of coil 1
CP1 Coil1Pump Coil1 pump control
b2 Valve2ONOFF Controls the ON/OFF valve of coil 2
b2O Valve2Open Controls opening of 3-point valve of coil 2
b2C Valve2Close Controls closing of 3-point valve of coil 2
b21 Coil2Step1 Controls step 1 of coil 2
b22 Coil2Step2 Controls step 2 of coil 2
b23 Coil2Step3 Controls step 3 of coil 2
CP2 Coil2Pump Coil2 pump control
b3 Valve3ONOFF Controls the ON/OFF valve of coil 3
b3O Valve3Open Controls opening of 3-point valve of coil 3
b3C Valve3Close Controls closing of 3-point valve of coil 3
