Air Handling seq. - user manual
5.2| Energy recovery
The energy recovery load demand is calculated by the damper sequence as it is for the mixing damper (see “6.1]
Damper control sequences”).
It is possible to manage the following output as described in gure.
ENERGY RECOVERY
Type of output Output used
digital output
ERD Recovery
ERP Recovery Pump
analog output ERA Recovery
Tab 24_ [Dampers and Energy recovery control - Energy recovery]
Fig 18 _ [Dampers and Energy recovery control - Energy recovery]
(See “4.6] Pumps control” ) for how to control the recovery pump.
