Danfoss MCX08M

Danfoss Electronics spa
Air Handling seq.- user manual
DKRCC.PS.RI.A1.02 / 520H4358 - Air Handling Seq. user manual - V 2.2
Produced by Danfoss Electronics spa Graphic Department, 10-2009
65
TABLE OF EXPORTED VARIABILES 1
Code Description Notes R/W Register
Address
Cool1 Req. Power R 43
Humidier Req. Power R 44
Dehumidier Req. Power R 45
Reserved R 46
Parameters
rst parameter See Congurator R/W 8194
......
Analog inputs (function)
Not Used 9249
SUP Supply Temp Supply air temperature R 9250
REt Return Temp Return air temperature R 9251
OUt Outside Temp Outside air temperature R 9252
tH1 Preheat Temp Pre-heating temperature R 9253
tH2 Reheat Temp Reheat Temp R 9254
tC1 Cooling Temp Cooling temperature R 9255
tC2 AntiFreeze Antifreeze temperature R 9256
bAR Air Pressure Air pressure R 9257
SHU Sup. Humidity Supply air humidity R 9258
RHU Ret. Humidity Return air humidity R 9259
CO2 CO2 Air carbon dioxide (CO2) measurement R 9260
VOC VOC Air volatile organic compounds (VOC)
measurement
R 9261
Analog outputs (function)
Not Used 10065
SUF Supply Fan Supply Fan control R 10066
REF Return Fan Return Fan control R 10067
RDA Mixing damper Mixing damper control R 10068
EDA External Damper External damper control R 10069
HUA Humidier Humidier control R 10070
bA1 Valve1 Valve 1 control R 10071
bA2 Valve2 Valve 2 control R 10072
bA3 Valve3 Valve 3 control R 10073
DHU Dehumidier Dehumidier control R 10074
ERA Recovery Energy recovery control R 10075
Internal variables
Reserved R 16641 - 16648
Main set heat R 16649
Main set cool R 16650
Cascade set heat R 16651
Cascade set cool R 16652
Reserved R 16653-16657
Heating1 Req. Power B1 R 16658
Heating1 Req. Power B2 R 16659
