Table 5-5 Suction Pressure Alarm and Fault Settings
Model
Alarm Fault
kPa(g) PSIG kPa(g) PSIG
TGS230ST 99 14 79 11
TGS230MT 40 6 29 4
TGS310 99 14 79 11
TGS390 99 14 96 14
TGS490 99 14 79 11
TGS520 99 14 96 14
TGH285ST 99 14 79 11
TGH285MT 5 0.73 -4 -0.6
TTS300ST 177 26 152 22
TTS300MT 91 13 76 11
TTS350 177 26 152 22
TTS400 177 26 166 24
TTS700 177 26 166 24
TTH375ST 177 26 152 22
TH375MT 43 6.3 32 4.6
NOTE
Pressure ratio is the ratio of absolute discharge to absolute suction pressure. It can be calculated as follows:
l (DP + 101) / (SP + 101) (kPa) OR
l (DP + 14.7) / (SP + 14.7) (psi)
All TTS/TGS/TTH/TGH Series Turbocor compressors were designed for use in stationary building applications and are
suitable for some marine applications (e.g., cruise ships, floating platforms). Danfoss Turbocor compressors are
produced for civilian use and are not intended for safety critical systems. Misapplication of a Turbocor compressor
will not be covered under Danfoss LLC’s Standard Warranty Terms and Conditions.
5.5 Standards Compliance
It is the responsibility of the Original Equipment Manufacturer (OEM) to ensure that proper safety protocols are in
place and that the chiller system has been designed in a manner that is compliant with all applicable local, national,
and international codes and regulatory requirements governing the use of refrigerants, pressure, vessels, and
electrical power. OEMs must also ensure compliance with the requirements stated in the refrigerant manufacturer’s
Material Safety Data Sheet (MSDS) and that other system components are compatible with the refrigerant, giving
special attention to elastomers and seals.
