Chapter 16.0 Physical Data
This section contains data relative to compressor mounting, service clearance, and piping connections.
NOTE
The dimensions in the following figures show measurements in metric with imperial in parenthesis.
Table 16-1 Physical Dimensions
Model Length Width Height
Shipping Weight
(Includes all shipping
material)
Compressor Total
Weight (Compressor
Only)
TTS300/TGS230 788 mm
(31.02")
518 mm
(20.4")
487 mm
(19.17)
134 kg (296 lbs) 123.4 kg (272 lbs)
TTS350/TGS310/TGS490 788 mm
(31.02")
518 mm
(20.4")
487 mm
(19.17")
143 kg (315 lbs) 132 kg (291 lbs)
TTS400/TGS390 788 mm
(31.02")
518 mm
(20.4")
487 mm
(19.17")
142 kg (312 lbs) 130.6 kg (288 lbs)
TTS700/TGS520 788 mm
(31.02")
518 mm
(20.4")
487 mm
(19.17")
144 kg (318 lbs) 132 kg (294 lbs)
TTH375/TGH285 932 mm
(36.7")
590 mm
(23.2")
487 mm
(19.17")
181 kg (400 lbs) 163.7 kg (361 lbs)
16.1 Clearance
Adequate clearance around the compressor is essential to facilitate maintenance and service. Removal of the
compressor top and service-side covers requires a minimum clearance of 600 mm (24”) and 406 mm (16”),
respectively.
NOTE
If insulators are used at the four mounting base points, the overall height of the compressor will change. Be sure to measure accordingly
based on the insulator used.
