VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
P40.38
Upper Detection
time of PID
feedback loss
0.000s～30.000s
0.000s
☆
P40.39
PID operation at
stop
0-No PID operation at stop#
1-PID operation at stop
0
☆
P40.40
PID command
for accel and
decel time
0.0s～6000.0s
0.0s
☆
P40.41
PID offset
selection
0-digital setting#
1-AI1#
2-AI2#
3-AI3(option card)
0
☆
P40.42
PID offset digital
setting
-100.0%～100.0%
0.0%
☆
41 Group Sleeping function
P41.00
Sleep mode and
wake up
selection
Unit’s digit: sleep mode selection
0:no sleep function
1:sleep by frequency
2:AI1 sleep (AI1 as pressure feedback)#
3:AI2 sleep(AI2 as pressure feedback)
4:AI3 sleep (AI3 as pressure feedback)#
3:AI4 sleep(AI4 as pressure feedback)
Ten’s digit :wake up mode selection
0:wake up by frequency
1:AI1 wake up (AI1 as pressure
feedback)#
2:AI2 wake up (AI2 as pressure
feedback)
3:AI3 wake up (AI3 as pressure
feedback)#
4:AI4 wake up (AI4 as pressure
feedback)
Hundred’s digit:Sleep wake direction
selection
0: positive direction
Sleep source (AI1 ~ AI4) > P41.03, inverter
will sleep
Wake-up source (AI1 ~ AI4) < P41.04, the
inverter will wake up
1: reverse direction
Sleep source (AI1 ~ AI4) < P41.03, inverter
sleep
Wake-up source (AI1 ~ AI4) > P41.04, the
inverter wakes up.
➢ When the sleep source and wakeup
source are the same, please pay
attention to the size relationship of
P41.03 and P41.04. If the parameter
setting is unreasonable, when the
wake-up condition is selected, even if
the sleep condition is established, the
sleep state cannot be entered, and
special attention is required when
using.
010
☆
P41.01
Sleep setting
value by
frequency
0.00Hz～600HZ,It will sleep if value is less
than this value
0.00Hz
☆
101
