P44.29
Logic bock 3
function
0:no function;
1:and;
2:or;
3:not and;
4:not or;
5: exclusive OR
6:Ref=1 effective;Ref2=1 ineffective
7:Ref1 up effective,Ref2 up ineffective
8:Ref1 up and signal reverse
9:Ref1 up and output 200ms pulse width
0
☆
P44.30
Logic block 4
threshold
parameter 1
00.00-98.99(function code index)
00.00
☆
P44.31
Logic block 4
threshold
parameter2
00.00-98.99(function code index)
00.00
☆
P44.32
Logic block 4
input source
Unit’digit：parameter 1 bit selection
0-F (Represent 0-15),P44.30 corresponds to
0-15 bit
Ten’digit:parameter 2 bit selection
0-F (Represent 0-15),P44.31 corresponds to
0-15 bit
0
☆
P44.33
Logic bock 4
function
0:no function;
1:and;
2:or;
3:not and;
4:not or;
5: exclusive OR
6:Ref=1 effective;Ref2=1 ineffective
7:Ref1 up effective,Ref2 up ineffective
8:Ref1 up and signal reverse
9:Ref1 up and output 200ms pulse width
0
☆
P44.34
Constant setting
1
0～65535
0
☆
P44.35
Constant setting
2
0～65535
0
☆
P44.36
Constant setting
3
0～65535
0
☆
P44.37
Constant setting
4
-9999～9999
0
☆
P44.38
Constant setting
1 as per bit
definition
0～65535(define as bit)
0
☆
P44.39
Constant setting
2 as per bit
definition
0～65535(define as bit)
0
☆
P44.40
Constant setting
3 as per bit
definition
0～65535(define as bit)
0
☆
P44.41
Constant setting
4 as per bit
definition
0～65535(define as bit)
0
☆
Constant setting for reference of variable selector or logic block input
45 Group Multi-functional counter
r45.00
Counter 1 input
value
The count value before the electronic gear,
that is, the number of pulses received by the
counter 1 hardware, 32-bit read-only data
-
●
r45.02
Counter 1 count
value
Count value after electronic gear, 32-bit
read-only data
-
●
