VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
05 Group Analog and Pulse output
Actual output Pulse
frequency
0:Common numeric output (DO2 P07.02)
1:high frequency pulse output (Hdo)
HDO output source
selection
0:Running frequency(0~max frequency)
1:Set frequency(0~max frequency)
2:output current(0~2times motor rated
current)
3:output torque(0~3times motor rated torque)
4:set torque(0~3times motor rated torque)
5:output voltage(0~2times motor rated
voltage)
6: DC bus voltage(0~2times drives standard
DC bus voltage)
7: output power(0~2times motor rated
power)
8:encoder rotating speed(0-maximum frequency
rotating speed)
9: AI1(0.00~10.00V)
10: AI2(0.00~10.00V)
11: AI3(0.00~10.00V)
12: AI4(0.00~10.00V)
HDO Minimum output
pulse frequency
0.00kHz~50.00kHz
HDO terminal output pulse frequencywhen
Output signal source=0
HDO Max output pulse
frequency
0.00kHz~50.00kHz
HDO terminal output pulse frequencywhen
Output signal source=maximum value
AO1 output function signal
selection
Same as P05.02 function description
The output error of AO1 can be corrected by P05.07 and P05.08, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.07 + P05.08 × AO.pAO.c: the actual output of AO1;
AO.p: AO1 Value before correction and AO.c, AO.p, 100.0% of P05.07 corresponds to 10V or 20mA.
AO2 output function signal
selection
Same as P05.02 function description
The output error of AO2 can be corrected by P05.11 and P05.12, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.11 + P05.12 × AO.pAO.c: the actual output of AO2;
AO.p: AO2 value before correction and AO.c, AO.p, 100.0% of P05.11 corresponds to 10V or 20mA.
