Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
06 Group Multi-function Digital input
r06.00
DI port status
Bit0～Bit8 Correspond to DI1～DI8
Bit12～Bit15 Correspond to VDI1～VDI4
-
●
P06.01
DI1 Numeric input function
0：No function
1：FORWARD
2：Reverse/Forward and reverse switchover
3：Three wire control
4：Forward jog command
5：Reverse jog command
6：Terminal UP
7：Terminal DOWN
8：Clear up UP/DOWN offset
9：Coast to stop/free stop
10：Fault reset
11：Reverse forbidden
12：Switching run command to Keypad
13：Switching run command to Communication
14：fast stop
15：external stop
16：Switch between motor 1 and motor 2
17：Pause operatoin
18：DC braking
19：Switch between torque and speed Control
20：Torque control diabled
21：Multi-step speed terminal 1
22：Multi-step speed terminal2
23：Multi-step speedterminal3
24：Multi-step speed terminal4
25：Frequency source switchover
26：Switch main frequency source to Numeric
frequency setting
27：Switch main frequency source to AI1
28：Switch main frequency source to AI2
1
★
P06.02
DI2 Numeric input function
2
★
P06.03
DI3 Numeric input function
4
★
P06.04
DI4 Numeric input function
10
★
P06.05
DI5(HDI) Numeric input
function
0
★
P06.06
DI6 Numeric input
function（option card）
0
★
P06.07
DI7 Numeric input
function（option card）
0
★
60
