Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
30 Group Modbus communication parameter
1～247
Different slaves on the same network should
set different local addresses;
0 is the broadcast address, all slave inverters
can be identified
0:1200 bps; 1:2400 bps
2:4800 bps; 3:9600 bps
4:19200 bps; 5:38400 bps
6:57600 bps; 7:115200 bps
0: 1-8-N-1
(1 start bit +8 data bits +1 stop bits )
1: 1-8-E-1
(1start bit +8 data bits +1 even parity +1 stop
bit)
2: 1-8-0-1
(1 star bit+8 data bits +1odd parity+1 stop
bits)
3: 1-8-N-2
(1 star bit+8 data bits+2 stop bits)
4: 1-8-E-2
(1 star bits+8 data bit+1 even parity+2 stop
bits)
5: 1-8-0-2
(1 start bit +8 data bits+1 odd parity+2 stop
bits)
1～20msThe delay time of the local to answer
the master
0.0s(disabled)～60.0s(works for master-slave
system) When this function code effective,if
slave do not receive data from master
overtime,it will trip as Er.485
Number of
frames
received by
Modbus
Each time a frame is received, this value is
incremented by 1,0 to 65535 cycles.
Number of
frames that
Modbus has
sent
Each time a frame is sent, this value is
incremented by 1,0 to 65,536 cycles.
Number of
error frames
received by
Modbus
Each time an CRC error frame is received,
this value is incremented by 1,0 to 65535
cycles; it can be used to judge the degree of
communication interference.
Modbus
master-slave
option
0: Slave#
1: Master(sent by broadcast )
Slave memory
when inverter
as master
1～9 corresponds to 0x7001～0x7009
