Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
P41.02
Wake up
threshold by
frequency
0.00hz～600.00hz, ,It will wake up if value is
bigger than this value
0.00Hz
☆
When selecting frequency sleep and frequency wake-up, it must be set by P41.01 < P41.02. When the frequency
source is PID setting, and the frequency wake-up must be set to PID shutdown operation: P40.39 = 1.
P41.03
Sleep setting
value by
pressure
0～100.0%
0.0%
☆
P41.04
Wake up
threshold by
pressure
0.～100.0%
0.0%
☆
P41.05
Sleep delay time
0.0s～6000.0s
0.0s
☆
P41.06
Wake up delay
up
0.0s～6000.0s
0.0s
☆
P41.07
Sleep
decelerating
time
Setting value decide by P03.16
P03.16 = 2, 0.00～600.00s;
P03.16 = 1, 0.0s～6000.0s;
P03.16 = 0, 0s～60000s
P41.07 set to 0,sleeping stop mode to free
coast。
0.00s
☆
42 Group Simple PLC
r42.00
PLC current
running mode
Read only
-
●
r42.01
PLC current
running
remaining time
Read only
-
●
r42.02
PLC times of
cycles
Read only
-
●
P42.03
Simple PLC
running mode
Unit’digit:#
0: single cycle then stop#
1: single cycle then keep last speed#
2: recycle#
3: Plc reset when single cycle stop
Ten’s digit:
0:power off without saving
1:power off with saving#
Hundred’digit:#
0:stop without saving 1:stop
with saving
0: Restart from the first stage; stop during
running (cause by the stop command, fault
or power loss), run from the first stage after
restart. 1: Continue to run from the stop
frequency; stop during running(cause by
stop command and fault), the inverter
willrecord the running time automatically,
enter into the stage after restart and keep
the remaining running at the setting
frequency.
003
☆
P42.04
PLC running
times
1～60000
1
☆
P42.05
PLC step 1
running time
0.0～6553.5 unit depend on P42.21
Notice:Running time do not conclude
acceleration and deceleration time,same as
following
0.0
☆
