Danfoss VFD500 Series User Manual

VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
r27.02
Direction
indicator
Bit0: direction of the running frequency (0-
positive direction; 1-negative direction, the
same below)
Bit1: Set the direction of the frequency
Bit2: direction of the main frequency
Bit3: direction of the secondary frequency
Bit4: Direction of the UpDown offset
Bit5: Direction of the encoder feedback
frequency
Reserved above Bit6
-
●
r27.03
Bus voltage
Unit：1V
-
●
r27.04
VF separation
setting
unit：0.1%
-
●
r27.05
Output voltage
unit：0.1V
-
●
r27.06
Output current
unit：0.1A
-
●
r27.07
Output current
percentage
unit：0.1%(100% of motor rated current)
-
●
r27.08
Output torque
0.1%
-
●
r27.09
Torque setting
0.1%
-
●
r27.10
Drives running
mode status 1
Bit0:Running status 0-Stop;1-Run
Bit1:Motor direction0-Forward;1-Reverse
Bit2:Ready signal:0-not ready;1-ready
Bit3:fault status 0-no fault;1-fault
Bit4～5:fault type:0-free stop;1-fast stop;2-
stop as per stop mode；3：continue to run
Bit6:jog status:0-no jog;1-jog status
Bit7:Auto tune :0-no;1-yes
Bit8:DC braking:0-Non DC braking;1-DC
braking
Bit9:Reserved
Bit10～11:Acceleration and Deceleration:
0:stop/zero output;1:speed up;2:slow down;
3:constant speed
Bit12:Warning status: 0:no warning;
1:warning
Bit13:current limit status:0-no;1-yes
Bit14:overvoltage stalladjustment:0-no ;1-
yes
Bit15:undervoltage stall adjustment :0-no;1-
yes
-
●
r27.11
Drives running
mode2
Bit0～1:current command source:0-keypad;
1-terminal ;2-communicatoin
Bit2～3:motor option:0-motor 1;1-motor 2
Bit4～5:current motor control:0-VF;1-SVC;2-
VC
Bit6～7:current running mode:0-speed;1-
torque;2-position
-
●
r27.13
Run time
monitoring
0～65535min
0min
●
r27.14
Accumulated
power on time
Unit:hour
-
●
r27.15
Accumulated
running time
Unit:hour
-
●
r27.18
Heat sink
temperature
Unit:0.1 ℃
-
●
r27.19
Main frequency
Unit:0.01Hz
-
●
93
