VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
P06.08
DI8 Numeric input
functionoption card
27Switch main frequency source to AI1
28Switch main frequency source to AI2
29Switch main frequency source to AI3
30Switch main frequency source to AI4
31Switch main frequency source to high-
frequency pulse input
32Switch main frequency source to
communication setting
33Switch auxiliary frequency source to
numeric frequency setting
34Accel and Decel time terminal 1
35Accel and Decel time termina2
36Accel and Decel Stop
37User-defined fault 1
38User-defined fault 2
39PID pause
40PID integral pause
41PID parameter Switchover
42PID Positive/negative reaction switch
43Preset PID terminal 1
44Preset PID terminal 2
45PID Main and Auxaliary command switch
46PID Main and Auxaliary feedback switch
47Simple PLC status reset
48Simple PLC time stop
49Swing frequency stop
50Counter 1 input
51Counter 1 reset/clear
52Counter 2 input
53Counter 1 reset/clear
54Clear/reset timed running time
55Motor 2 Accel and Decel time selection
0
P06.09
DI9 Numeric input
functionoption card
0
P06.13
VDI1 Numeric input
functionVirtual DI
0
P06.14
VDI2 Numeric input
functionVirtual DI
0
P06.15
VDI3 Numeric input
functionVirtual DI
0
P06.16
VDI4 Numeric input
functionVirtual DI
0
P06.17
Virtual input source
Unit’digit: VDI1 input source
0~F: P06.33 specifies the bit0~bit15 of the
parameter
Ten’s digit: VDI2 input source
0~F: P06.34 specifies the bit0~bit15 of the
parameter.
Hundred’s digit: VDI3 input source
0~F: P06.35 specifies the bit0~bit15 of the
parameter
Thousand’s digit: VDI4 input source
0~F: P06.36 specifies the bit0~bit15 of the
parameter
0003
P06.18
DI Forcing function
Define as per bit :Disable;1:Enable
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
When the bit is enabled, the state of the DI or
VDI is set by the corresponding bit of P06.19.
H00000000
L00000000
P06.19
DI Forcing data
Define as per bit 0:effective;1:ineffective
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
0
P06.20
Effective logic of
Numericinput terminal
Define as per bit 0:positive logic;1:negative logic
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
In the reverse logic, the inactive level of the DI
terminal becomes the active level.
0
P06.21
DI1 Effective delay time
0.000s30.000s
0.000s
61
