VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
P04.23
Curve A
horizontal axis 1
0.00V～
P04.25
0.00V
☆
P04.24
Curve Avertical
axis 1
-100.0%
～
100.0%
0.0%
☆
P04.25
Curve A
horizontal axis 2
P04.23～
10.00V
10.00V
☆
P04.26
Curve A vertical
axis 2
-100.0%
～
100.0%
100.0%
☆
P04.27
Curve B
horizontal axis 1
0.00V～
P04.29
0.00V
☆
P04.28
Curve B vertical
axis 1
-100.0%
～
100.0%
0.0%
☆
P04.29
Curve B
horizontal axis 2
P04.27～
10.00V
10.00V
☆
P04.30
Curve B vertical
axis 2
-100.0%
～
100.0%
100.0%
☆
P04.31
Curve C
horizontal axis 1
0.00V～
P04.33
0.00V
☆
P04.32
Curve C vertical
axis 1
-100.0%
～
100.0%
0.0%
☆
P04.33
Curve C
horizontal axis 2
P04.31～
P04.35
3.00V
☆
P04.34
Curve C vertical
axis 2
-100.0%
～
100.0%
30.0%
☆
P04.35
Curve C
horizontal axis 3
P04.33～
P04.37
6.00V
☆
P04.36
Curve C vertical
axis 3
-100.0%
～
100.0%
60.0%
☆
P04.37
Curve C
horizontal axis 4
P04.35～
10.00V
10.00V
☆
Functio
n code
Parameter
name
Description
Default
Propert
y
Note:input less than P04.23,output
decided by curve ten’s digit
P04.25
P04.2
6
AI
Correspondin
g setting
P04.2
3
P04.2
4
Note:input less than P04.31,output
decided by curve ten’s digit
P04.33
P04.34
P04.38
P04.35
AI
Corresponding setting
P04.31
P04.32
P04.36
P04.37
if you want to use 4-20MA,Set 04.27=2.00V
Note:input less than
P04.27,output decide by curve
ten’s digit
P04.29
P04.30
AI
Correspondi
ng setting
P04.27
P04.28
57
