Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
P07.03
Relay 1 Output terminal
function group(T1A T1B
T1C)
3:Error1（stop fault）
4:Error2（same as Error1 except undervoltage）
5:Error 3 t(fault but It still keeps running)
6:Swing frequency limit
7:Torque limit
8:Reverse running
9: Upper limit frequency arrival
10:Lower limit frequency arrival 1
11: Lower limit frequency arrival2
12:FDT1 output frequency detection range
13:FDT2 output frequency detection range
14:Setting frequency arrival
15:Desired frequency attained 1 P08.05
16:Desired frequency attained 2P08.07
17:Zero speed （stop without output）
18: Zero speed （stop with output）
19:Zero current status
20:Output current exceed limit
21:Counter 1 setting value arrival
22:Counter 1 setting value arrival
23:Simple PLC cycle finish
24:Reserved
25:Drive overload pre-warning
26: Motor overload pre-warning
27: Motor overheat pre-warning
28:Off loading
29:Reserved
30:Reserved
31: Reserved
32:Variable selector unit 1 output
33:Variable selector unit 2 output
34:Variable selector unit 3 output
35:Variable selector unit 4 output
36:Logic unit 1 output
37:Logic unit 2 output
38:Logic unit 3 output
39:Logic unit 4 output
40:Delaying unit 1 output
41:Delaying unit 2 output
42: Delaying unit 3 output
43: Delaying unit 4 output
44: Reserved
45: Reserved
3
☆
P07.04
Relay 2 Output terminal
function group(T2A T2B
T2C)
0
☆
P07.05
DO3 Output terminal
function group(IO card)
0
☆
P07.06
DO4 Output terminal
function group(IO card)
0
☆
P07.07
DO5 Output terminal
function group(IO card)
0
☆
P07.08
DO6 Output terminal
function group(IO card)
0
☆
P07.09
VDO1(virtual DO1) output
Terminal function
0
☆
P07.10
VDO2(virtual DO2) output
Terminal function
0
☆
64
