VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
21 Group Keypad and Display Group
P21.00
Keyboard
UP/DOWN function
Units: UP/DOWN enable selection 0: Disable 1:
Enable
Ten’unit: clear selection 0: Cleared in non-
operational state 1: Not cleared
Hundred's unit: Power-down memory selection 0:
no memory 1: memory
Thousand’s unit: rate selection 0: automatic rate
1: P01.39 rate
0111
★
P21.02
MK function option
0：no function; 1：Forward Jog
2：Reverse Jog; 3：Forward/reverse Switch
4：Quick stop; 5：coast to stop
6：Curse left shift(LCD keypad )
1
★
P21.03
STOP function
0:Valid only at Keypad Control
1:valid at all command Channels
1
☆
P21.04
Monitoring display1
00.00～99.99
27.00
☆
P21.05
Monitoring display2
00.00～99.99
27.01
☆
P21.06
Monitoring display3
00.00～99.99
27.06
☆
P21.07
Monitoring display4
00.00～99.99
27.05
☆
P21.08
Monitoring display5
00.00～99.99
27.03
☆
P21.09
Monitoring display6
00.00～99.99
27.08
☆
P21.10
Monitoring display7
00.00～99.99
06.00
☆
P21.11
Running status Monitoring
display parameter option
Unit’digit to Thousand’digit set 1-4 monitor
parameter
0 means no display，1～7 corresponds to
monitor parameter 1～7
Unit’digit：choose first monitoring data，0～7
Ten’s digit：choose second monitoring data，0
～7
Hundred’s digit：choose third monitoring data，0
～7
Thousand’s digit：choose fourth monitoring
display，0～7
5321
☆
P21.22
Stop status Monitoring
display parameter option
Same as P21.11
0052
☆
81
