Danfoss VLT 5000 FLUX User Manual

VLT
®
5000 FLUX
■ Mechanical dimensions
All the below listed measurements are in mm.
ABCDabab/beType
Bookstyle IP 20
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
395 90 260 384 70 100 A
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
395 130 260 384 70 100 A
Compact IP 00
5032 - 5052 200 - 240 V 800 370 335 780 270 225 B
5122 - 5152 380 - 500 V 1046 408 375
2)
1001 304 225 J
5202 - 5302 380 - 500 V 1327 408 375
2)
1282 304 225 J
5350 - 5500 380 - 500 V 1896 1099 494 1847 1065 400
1)
I
Compact IP 20
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
395 220 160 384 200 100 C
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
395 220 200 384 200 100 C
5008 200 - 240 V
5016 - 5022 380 - 500 V
560 242 260 540 200 200 D
5011 - 5016 200 - 240 V
5027 - 5032 380 - 500 V
700 242 260 680 200 200 D
5022 - 5027 200 - 240 V
5042 - 5062 380 - 500 V
800 308 296 780 270 200 D
5072 - 5102 380 - 500 V 800 370 335 780 330 225 D
Compact Nema 1/IP20/IP21
5032 - 5052 200 - 240 V 954 370 335 780 270 225 E
5122 - 5152 380 - 500 V 1208 420 373
2)
1154 304 225 J
5202 - 5302 380 - 500 V 1588 420 373
2)
1535 304 225 J
5350 - 5500 380 - 500 V 2010 1200 600 - - 400
1
H
Compact IP 54/Nema 12
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
460 282 195 85 260 258 100 F
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
530 282 195 85 330 258 100 F
5008 - 5011 200 - 240 V
5016 - 5027 380 - 500 V
810 350 280 70 560 326 200 F
5016 - 5027 200 - 240 V
5032 - 5062 380 - 500 V
940 400 280 70 690 375 200 F
5032 - 5052 200 - 240 V 937 495 421 - 830 374 225 G
5072 - 5102 380 - 500 V 940 400 360 70 690 375 225 F
5122 - 5152 380 - 500 V 1208 420 373
2)
- 1154 304 225 J
5202 - 5302 380 - 500 V 1588 420 373
2)
1535 304 225 J
5350 - 5500 380 - 500 V 2010 1200 600 - - - 400
1)
H
ab: Minimum space above enclosure’
be: Minimum space below enclosure
1: Only above enclosure (ab) IP 00 when built in a
Rittal cabinet.
2: With disconnect, add 42 mm.
MG.55.A6.02 - VLT is a registered Danfoss trademark
14
