Danfoss VLT 5000 FLUX User Manual

VLT
®
5000 FLUX
Programming
128 must be programmed for Thermistor warning
[1] or Thermistor trip [2].
Speed limit is used if speed limit value set in Parameter
202 is changed by means of an analog signal.
308 Terminal 53, analog input voltage
(AI [V] 53 FUNCT.)
Value:
See the Analog Inputs table.
Function:
Selectionofthedesiredoptiononterminal53.Scaling
of input signal is selected in parameter 309 and 310.
Description of choice:
See the section Analog Input Functions.
309 Terminal 53, min. scaling
(AI 53 SCALE LOW)
Value:
0.0 - 10.0 Volt
✭ 0.0 Volt
Function:
This parameter is used for setting the analog input
scaling value that corresponds to the minimum
reference value set in parameter 204.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
310 Terminal 53, max. scaling
(AI 53 SCALE HIGH)
Value:
Parameter 309 - 10.0 Volt
✭ 10.0 Volt
Function:
Is used for setting the scaling value that relates to the
maximum reference value set in parameter 205.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
311 Terminal 54, analog input voltage
(AI [V] 54 FUNCT.)
Value:
See the Analog Inputs table.
Function:
Selection of the desired option on terminal 54. Scaling
of input signal is selected in parameter 312 and 313.
Description of choice:
See the section Analog Input Functions.
312 Terminal 54, min. scaling
(AI 54 SCALE LOW)
Value:
0.0 - 10.0 Volt
✭ 0.0 Volt
Function:
This parameter is used for setting the scaling
value that corresponds to the minimum reference
value set in parameter 204.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
313 Terminal 54, max. scaling
(AI 54 SCALE HIGH)
Value:
Parameter 312 - 10.0 Volt
✭ 10.0 Volt
Function:
This parameter is used for setting the scaling
value that corresponds to the maximum reference
value set in parameter 205.
Description of choice:
Set the desired voltage value.
See also section Handling of single references.
314 Terminal 60, analog input current
(AI [MA] 60 FUNCT)
Value:
See the Analog Inputs table.
Function:
Selection of the desired option on terminal 60.
Scaling of analog current input signal is selected
in parameter 315 and 316.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.55.A6.02 - VLT is a registered Danfoss trademark
93
