Programming
Description of choice:
Select Upload all parameters [1] if all parameter values
are to be transmitted to the control panel.
Select Download all parameters [2] if all transmitted
parameter values are to be copied to the frequency
converter on which the control panel has been mounted.
Select Download power-independent par. [3] if only the
power-independent parameters are to be downloaded.
This is used if downloading to a frequency converter
that has a different rated power that the one from
where the parameter Setup originates.
Please note that the power-dependent parameter
102-106 must be programmed after copying.
NB!:
Uploading/Downloading can only be carried
out in the Stop mode.
008 Display scaling speed
(SPEED SCALE)
Value:
0.01 - 100.00
✭ 1
Function:
This parameter chooses the factor to be multiplied
by the motor speed, for presentation in the
display, when parameter 009-012 have been
set for Speed x Scaling [5].
Description of choice:
Set the desired scaling factor.
009 Display line 2
(DISPLAY LINE 2)
Value:
Reference [%] (REFERENCE [%])
[1]
Reference [unit] (REFERENCE [UNIT])
[2]
Frequency [Hz] (FREQUENCY [HZ])
[4]
✭Speed [RPM] (SPEED [RPM])
[5]
Motor current [A] (MOTOR CURRENT [A])
[6]
Torque [%] (TORQUE [%])
[7]
Power [kW] (POWER [KW])
[8]
Power [HP] (POWER [HP] [US])
[9]
Output energy [kWh]
(OUTPUT ENERGY [KWH])
[10]
Motor voltage [V] (MOTOR VOLTAGE [V])
[11]
DC link voltage [V] (DC LINK VOLTAGE [V])
[12]
Thermal load, motor [%]
(MOTOR THERMAL [%])
[13]
Thermal load, VLT [%] (VLT THERMAL [%])
[14]
Hours run [Hours] (RUNNING HOURS)
[15]
Digital input [Binary code]
(DIGITAL INPUT [BIN])
[16]
Analog input 53 [V] (ANALOG INPUT 53 [V])
[17]
Analog input 54 [V] (ANALOG INPUT 54 [V])
[18]
Analog input 60 [mA]
(ANALOG INPUT 60 [MA])
[19]
Pulse reference [Hz] (PULSE REF. [HZ])
[20]
External reference [%] (EXTERNAL REF [%])
[21]
Status word [Hex] (STATUS WORD [HEX])
[22]
Brake effect/2 min. [KW]
(BRAKE ENERGY/2 MIN)
[23]
Brake effect/sec. [kW] (BRAKE ENERGY/S)
[24]
Heat sink temp. [°C] (HEATSINK TEMP [°C])
[25]
Alarm word [Hex] (ALARM WORD [HEX])
[26]
Control word [Hex]
(CONTROL WORD [HEX])
[27]
Warning word 1 [Hex]
(EXT. STAT. WORD [HEX])
[28]
Warning word 2 [Hex]
(WARNING WORD 2 [HEX])
[29]
Digital Output [Bin]
(DIGITAL OUTPUT [BIN])
[30]
Communication option card warning
(COMM OPT WARN [HEX])
[31]
KTY sensor [°C] (KTY SENSOR TEMP)
[32]
Function:
This parameter allows a choice of the data value
to be displayed in line 2 of the display.
Parameter 010-012 enable the use of three additional
data values to be displayed in line 1.
Description of choice:
Reference [%] corresponds to the total
reference (sum of digital/analog/preset/bus/freeze
ref./catch-up and slow-down).
Reference [unit] gives the status value of terminals
17/29/53/54/60 using the unit stated on the basis
of configuration in parameter 100 (rpm).
Frequency [Hz] gives the motor frequency, i.e. the
output frequency from the frequency converter.
Speed [RPM] Display the speed in RPM (Rounds per
Minute) i.e. the motor shaft speed in closed loop.
Motor current [A] states the phase current of the
motor measured as effective value.
Torque [%] gives the current motor load in
relation to the rated motor torque.
Power [kW] states the actual power consumed
by the motor in kW.
Power [HP] states the actual power consumed
by the motor in HP.
Output energy [kWh] states the energy
consumed by the motor since the latest reset
was made in parameter 618.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.55.A6.02 - VLT is a registered Danfoss trademark
63
