■ Tightening-up torques and screw sizes
The table shows the torque required when fitting
terminals to the frequency converter. For VLT
5001-5027 200-240 V and VLT 5001-5102 380-500
V, the cables must be fastened with screws. For VLT
5032-5052 200-240 V and VLT 5122-5500 380-500
V, the cables must be fastened with bolts.
These figures apply to the following terminals:
Mains terminals Nos 91, 92, 93
L1, L2, L3
Motor terminals Nos 96, 97, 98
U, V, W
Earth terminal No 94, 95, 99
Brake resistor terminals 81, 82
Loadsharing 88, 89
VLT type
200-240 V
Torque [Nm] Screw/
Boltsize
Tool
5001-5006 0,6 M3 Slotted screw
5008 IP20 1,8 M4 Slotted screw
5008-5011 IP54 1,8 M4 Slotted screw
5011-5022 IP20 3 M5 4 mm Allen wrench
5016-5022
3)
IP54 3 M5 4 mm Allen wrench
5027 6 M6 4 mm Allen wrench
5032-5052
1)
11,3 M8 (bolt and stud)
380-500 V
5001-5011 0,6 M3 Slotted screw
5016-5022 IP20 1,8 M4 Slotted screw
5016-5027 IP54 1,8 M4 Slotted screw
5027-5042 IP20 3 M5 4 mm Allen wrench
5032-5042
3)
IP54 3 M5 4 mm Allen wrench
5052-5062 6 M6 5 mm Allen wrench
5072-5102 IP20 15 M6 6 mm Allen wrench
IP54
2)
24 M8 8 mm Allen wrench
5122-5302
4)
19 M10 bolt
5350-5500
5)
42 M12 bolt
1) Brake terminals: 3,0 Nm, Nut: M6
2) Brake and loadsharing: 14 Nm, M6 Allen screw
3) IP54 with RFI - Line terminals 6Nm, Screw: M6 - 5 mm Allen wrench
4) Loadshare and brake terminals: 9,5 Nm; Bolt M8
5) Brake terminals: 11,3 Nm; Bolt M8
