Danfoss VLT 5000 FLUX User Manual

VLT
®
5000 FLUX
Programming
■ References and limits
■ Introduction
The purpose of the parameter group 2xx is selecting and adjusting references, ramping times and setting
limits for warnings.
Actual reference Resulting reference for speed/torque
External reference Reference on Terminals 53, 54 or 60, and puls and bus references
Preset reference Reference value from the internal four presets.
PNU Parameter Factory setting Range Changes 4-Setup Conversion Data
# description during operation index type
200 Output speed range/direction Only clockwise, 0-4500
rpm
No Yes 0 5
202 Output speed high limit 3000 rpm n
MIN
-par. 200 No Yes -1 6
203 Reference Range Min - max Yes Yes 0 5
204 Minimum reference 0.000 -100,000.000-Ref
MAX
Yes Yes -3 4
205 Maximum reference 1500.000 Ref
MIN
-100,000.000 Yes Yes -3 4
206 Ramp type Linear Yes Yes 0 5
207 Ramp-up time 1 Depends on unit 0.01 - 3600 Yes Yes -2 7
208 Ramp-down time 1 Depends on unit 0.01 - 3600 Yes Yes -2 7
209 Ramp-up time 2 Depends on unit 0.01 - 3600 Yes Yes -2 7
210 Ramp-down time 2 Depends on unit 0.01 - 3600 Yes Yes -2 7
211 Jog ramp time Depends on unit 0.01 - 3600 Yes Yes -2 7
212 Quick stop ramp-down time Depends on unit 0.01 - 3600 Yes Yes -2 7
213 Jog speed 200 rpm 0.0 - par. 202 Yes Yes -1 6
214 Reference function Sum Yes Yes 0 5
215 Preset reference 1 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
216 Preset reference 2 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
217 Preset reference 3 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
218 Preset reference 4 0.00 % - 100.00 - 100.00 % Yes Yes -2 3
219 Catch up/slow down value 0.00 % 0.00 - 100 % Yes Yes -2 6
221 Torque limit for motor mode 160 % 0.0 % - xxx % Yes Yes -1 6
222 Torque limit for generating
operation
160 % 0.0 % - xxx % Yes Yes -1 6
223 Warning: Low current 0.0 A 0.0 - par. 224 Yes Yes -1 6
224 Warning: High current I
VLT,MAX
Par. 223 - I
VLT,MAX
Yes Yes -1 6
225 Warning: Low speed 0 rpm 0 - par. 226 Yes Yes -1 6
226 Warning: High speed 100.000 rpm Par. 225 - par. 202 Yes Yes -1 6
234 Motor phase monitor Enable Yes Yes 0 5
235 Phase loss monitor Enable No No 0 5
236 Low Speed Current 100% 0 – Motor size depended Yes Yes 0 6
237 Model Shift Speed 20% of n
nom
10 Hz Yes No 0 6
240 Acceleration Jerk 1 33% 0-100% No No 0 U16
241 Acceleration Jerk 2 33% 0-100% No No 0 U16
242 Deceleration Jerk 1 33% 0-100% No No 0 U16
243 Deceleration Jerk 2 33% 0-100% No No 0 U16
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.55.A6.02 - VLT is a registered Danfoss trademark
79
