Danfoss VLT 5000 FLUX User Manual

VLT
®
5000 FLUX
■ Compact, Mains supply 3 x 380-500 V
According to international requirements VLT type 5350 5450 5500
Normal overload current (110 %):
Output current I
VLT,N
[A] (380-440 V) 600 658 745
I
VLT, MAX
(60 s) [A] (380-440 V) 660 724 820
I
VLT,N
[A] (441-500 V) 540 590 678
I
VLT, MAX
(60 s) [A] (441-500 V) 594 649 746
Output S
VLT,N
[kVA] (400 V) 416 456 516
S
VLT,N
[kVA] (460 V) 430 470 540
S
VLT,N
[kVA] (500 V) 468 511 587
Typical shaft output [kW] (400 V) 315 355 400
[HP] (460 V) 450 500 600
[kW] (500 V) 355 400 500
High overload torque (160 %):
Output current I
VLT,N
[A] (380-440 V) 480 600 658
I
VLT, MAX
(60 s) [A] (380-440 V) 720 900 987
I
VLT,N
[A] (441-500 V) 443 540 590
I
VLT, MAX
(60 s) [A] (441-500 V) 665 810 885
Output S
VLT,N
[kVA] (400 V) 333 416 456
S
VLT,N
[kVA] (460 V) 353 430 470
S
VLT,N
[kVA] (500 V) 384 468 511
Typical shaft output [kW] (400 V) 250 315 355
[HP] (460 V) 350 450 500
[kW] (500 V) 315 355 400
Max. cable cross-section to
motor and loadsharing
[mm
2
]
4,6
[AWG]
2,4,6
2x400 - 3x150
2x750 mcm - 3x350 mcm
Max. cable cross-section
to brake
[mm
2
]
4,6
[AWG]
2,4,6
70
2/0
Normal overload current (110 %):
Rated input current I
L,N
[A] (380-440 V) 584 648 734
I
L,N
[A] (441-500 V) 526 581 668
High overload torque (160 %):
Rated input current I
L,N
[A] (380-440 V) 467 584 648
I
L,N
[A] (441-500 V) 431 526 581
Max. cable cross-section
power supply
[mm
2
]
4,6
[AWG]
2,4,6
2x400 - 3x150
2x750 mcm - 3x350 mcm
Min. cable cross-section to
motor, power supply and
loadsharing
[mm
2
]
4,6
[AWG]
2,4,6
70
3/0
Min. cable cross-section to
brake
[mm
2
]
4,6
[AWG]
2,4,6
10
8
Max. pre-fuses (mains) [-]/UL [A]
1
700/700 800/800 800/800
Efficiency
3
0,97
Power loss Normal overload [W] 11300 12500 14400
High overload [W] 9280 11300 12500
Weight IP 00 [kg] 515 560 585
Weight IP 21/Nema1 [kg] 630 675 700
Weight IP 54/Nema12 [kg] 640 685 710
Enclosure IP 00, IP 20/Nema 1 and IP 54/Nema12
1. For type of fuse see section Fuses
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Max. cable cross-section is the maximum possible cable cross-section allowed to be fitted on the terminals. Min. cable cross-section is the minimum
allowed cross-section. Always comply with national and local regulations on min. cable cross-section.
5. Weight without shipping container.
6. Connection bolt power supply, motor and loadsharing: M12; Brake: M8
MG.55.A6.02 - VLT is a registered Danfoss trademark
152
