Danfoss VLT AQUA Drive FC 202

Model
525–550 V
551–690 V
N200
22
14
20
13
N250
32
22
29
20
N315
45
32
41
29
N355
61
45
56
41
N400
43
30
39
28
N500
53
36
49
33
N560
69
53
63
49
N630
77
69
77
63
N710
84
63
77
57
N800
114
84
104
77
11.6.5 Passive Harmonic Filter Losses
Table 150: Power Losses for Passive Harmonic Filter Option, 380–480 V (Losses Shown in Watts)
Model
380–440 V
441–480 V
–
NO
HO
NO
HO
N110
1083
841
1083
841
N132
1284
1083
1284
1083
N160
1511
1284
1511
1284
N200
1704
1511
1704
1511
N250
1814
1704
1814
1704
N315
2242
1814
1980
1814
N355
2302
2242
2242
1980
N400
2498
2302
2302
2242
N450
2613
2498
2498
2302
N500
2838
2613
2613
2498
N560
3160
2838
2838
2613
Table 151: Power Losses for Passive Harmonic Filter Option, 525–690 V (Losses Shown in Watts)
Model
525–550 V
551–690 V
–
NO
HO
NO
HO
N110
3406
2689
2689
2151
N132
4302
3406
3406
2689
N160
5199
4302
4302
3406
N200
6454
5199
5199
4302
