Illustration 46: Motor Heater Control (A = Heater element, not included)
5.7.6.8 Insulation Monitor
Table 61: Auxiliary Function Type Codes
AC socket+cabinet light + insulation monitor
AC socket+cabinet light + extended I/O terminals + insulation monitor
AC socket+cabinet light + extended I/O terminals + cabinet heater + insulation monitor
AC socket+cabinet light + extended I/O terminals + motor heater control + insulation monitor
AC socket+cabinet light + extended I/O terminals + cabinet heater + motor heater control + insulation
monitor
AC socket+cabinet light + cabinet heater + insulation monitor
AC socket+cabinet light + cabinet heater + motor heater control + insulation monitor
AC socket+cabinet light + motor heater control + insulation monitor
Extended I/O terminals + insulation monitor
Extended I/O terminals + cabinet heater + insulation monitor
Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
Extended I/O terminals + motor heater control + insulation monitor
Cabinet heater + insulation monitor
Cabinet heater + motor heater control + insulation monitor
Motor heater control + insulation monitor
The insulation monitor option monitors the supply and insulation faults within the insulation level in an IT supply network with an
insulation monitor in the control compartment.
5.7.6.9 Signal Lights and Reset Buttons
Table 62: Door-mounted Option Type Codes
Signal lights and reset button
Signal lights and reset button + emergency switch o and emergency push-button
Signal lights and reset button + STO with emergency push-button (no functional safety)
Signal lights and reset button + STO/SS1 with emergency push-button + safely limited speed (TTL
encoder)
