Danfoss VLT AQUA Drive FC 202

130BF362.10
290 (11.4) 0.0 257 (10.1) 309 (12.1) 0.0
2
1
3
1 Brake terminals 3 Motor terminals
2 Mains terminals – –
Illustration 5.28 D7h Terminal Dimensions with Brake Option (Side Views)
