Danfoss VLT AutomationDrive FC 300 Series Design Guide

FC 300 Design Guide
How to Program
Range:
-32767 - 32767
*
0
Function:
Describes the error and is m o stly used in
combination with alarm 38 "internal fault".
15-32 Fault Log: Time
Array [10]
Range:
0 - 2147483647
*
0
Function:
Shows when the logged event occurred.
Time is measured in s.
" 15-4* Drive Identi fication
15-40 FC Type
Function:
FC type. The readout is equal to the FC
300 Series power field of the type code
definition (characters 1-6 ).
15-41 Power Section
Function:
FC type. The readout equals the FC 300 Series power
field of the type code definition (characters 7-10).
15-42 Voltage
Function:
FC typ e. The read
outequalstheFC300Seriespower
field of the type code definition (characters 11-12).
15-43 Software Version
Function:
Displays the
combined SW versio n (or "package
version") consisting of power SW and control SW.
15-44 Ordered Typecode String
Function:
Shows the type code string used for re-ordering
the drive in its original configuration.
15-45 Actual Type code String
Function:
Shows th
eactualtypecodestring.
15-46 Adj Freq Dr Ordering No.
Function:
Shows the 8-digit ordering number used for
re-ordering the drive in its original configuration.
15-47 Po wer Card Ordering No.
Function:
Shows the power card ordering number.
15-48 LCP ID Num.
Function:
Shows the LCP ID number.
15-49 SW ID Control Card
Function:
Shows the control card software version number.
15-50 SW ID Power Card
Function:
Shows the power card software version number.
15-51 Adj Freq Dr Serial No.
Function:
Shows the drive serial number.
15-53 Power Card Serial Number
Function:
Shows the power card serial number.
" 15-6* Option Ident.
15-60 Option Mounted
Function:
Shows the type code string for the optio n (AX if no
option) and the translation i.e. "N o option".
15-61 Option SW Version
Function:
Shows the option slot A software version.
15-62 Option Ordering No
Function:
Shows the option slot A ordering number.
*
default setting ()display text []value for use in communication via serial communication port
212
MG.33.B
3.22 - VLT is a registered Danfoss trademark
