Danfoss VLT FC 103 Instruction Manual

Adjustable frequency drive
Typical Shaft Output [kW]
P11K
11
P15K
15
P18K
18.5
P22K
22
P30K
30
Typical Shaft Output [HP] at 460 V 15 20 25 30 40
IP20/Chassis
7)
B3 B3 B3 B4 B4
IP21/NEMA 1 B1 B1 B1 B2 B2
IP55/Type 12 B1 B1 B1 B2 B2
IP66/NEMA 4X B1 B1 B1 B2 B2
Output current
Continuous (3x380–439 V) [A] 24 32 37.5 44 61
Intermittent (3x380–439 V) [A] 26.4 35.2 41.3 48.4 67.1
Continuous (3x440–480 V) [A] 21 27 34 40 52
Intermittent (3x440–480 V) [A] 23.1 29.7 37.4 44 61.6
Continuous kVA (400 V AC) [kVA] 16.6 22.2 26 30.5 42.3
Continuous kVA (460 V AC) [kVA] 16.7 21.5 27.1 31.9 41.4
Max. input current
Continuous (3x380–439 V) [A] 22 29 34 40 55
Intermittent (3x380–439 V) [A] 24.2 31.9 37.4 44 60.5
Continuous (3x440–480 V) [A] 19 25 31 36 47
Intermittent (3x440–480 V) [A] 20.9 27.5 34.1 39.6 51.7
Additional specifications
Estimated power loss at rated max. load [W]
4)
278 392 465 525 698
IP20 max. cable cross-section (line power, brake,
motor and load sharing)
16, 10, - (8, 8, -) 35, -, - (2, -, -) 35 (2)
IP21, IP55, IP66 max. cable cross-section (line
power, motor) [mm
2
/(AWG)]
10, 10, 16 (6, 8, 6) 35, 25, 25 (2, 4, 4) 50 (1)
IP21, IP55, IP66 max. cable cross-section (brake,
load sharing) [mm
2
/(AWG)]
10, 10, - (8, 8, -) 35, -, - (2, -, -) 50 (1)
With line power disconnect switch included: 16/6
Weight enclosure IP20 (lb [kg]) 26.46 [12] 26.46 [12] 26.46 [12] 51.81 [23.5] 51.81 [23.5]
Weight enclosure IP21 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 59.53 [27]
Weight enclosure IP55 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 59.53 [27]
Weight enclosure IP66 (lb [kg]) 50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 59.53 [27]
Efficiency
3)
0.98 0.98 0.98 0.98 0.98
Table 10.4 Line Power Supply 3x380–480 V AC – Normal overload 110% for 1 minute
Specifications Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 79
