Adjustable frequency drive
Typical Shaft Output [kW]
P37K
37
P45K
45
P55K
55
P75K
75
P90K
90
Typical Shaft Output [HP] at 460 V 50 60 75 100 125
IP20/Chassis
7)
B4 C3 C3 C4 C4
IP21/NEMA 1 C1 C1 C1 C2 C2
IP55/Type 12 C1 C1 C1 C2 C2
IP66/NEMA 4X C1 C1 C1 C2 C2
Output current
Continuous (3x380–439 V) [A] 73 90 106 147 177
Intermittent (3x380–439 V) [A] 80.3 99 117 162 195
Continuous (3x440–480 V) [A] 65 80 105 130 160
Intermittent (3x440–480 V) [A] 71.5 88 116 143 176
Continuous kVA (400 V AC) [kVA] 50.6 62.4 73.4 102 123
Continuous kVA 460 V AC) [kVA] 51.8 63.7 83.7 104 128
Max. input current
Continuous (3x380–439 V) [A] 66 82 96 133 161
Intermittent (3x380–439 V) [A] 72.6 90.2 106 146 177
Continuous (3x440–480 V) [A] 59 73 95 118 145
Intermittent (3x440–480 V) [A] 64.9 80.3 105 130 160
Additional specifications
Estimated power loss at rated max. load [W]
4)
739 843 1083 1384 1474
IP20 max. cable cross-section (line power, brake,
motor and load sharing)
50 (1) 150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (line power,
motor) [mm
2
/(AWG)]
150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (brake, load
sharing) [mm
2
/(AWG)]
95 (3/0)
With line power disconnect switch included: 35/2 35/2 70/3/0 185/kcmil350
Weight enclosure IP20 (lb [kg]) 51.81 [23.5] 77.16 [35] 77.16 [35] 110.23 [50] 110.23 [50]
Weight enclosure IP21 (lb [kg]) 99.21 [45] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65]
Weight enclosure IP55 (lb [kg]) 99.21 [45] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65]
Weight enclosure IP66 (lb [kg]) 99.21 [45] 99.21 [45] 99.21 [45] 143.3 [65] 143.3 [65]
Efficiency
3)
0.98 0.98 0.98 0.98 0.99
Table 10.5 Line Power Supply 3x380–480 V AC – Normal overload 110% for 1 minute
Specifications Instruction Manual
80 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG16E222
