Danfoss VLT FC 103 Instruction Manual

10.1.3 Line Power Supply 3x525–600 V AC
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P3K7
3.7
P4K0
4
P5K5
5.5
P7K5
7.5
IP20/Chassis A3 A3 A3 A3 A2 A3 A3 A3
IP21/NEMA 1 A3 A3 A3 A3 A2 A3 A3 A3
IP55/Type 12 A5 A5 A5 A5 A5 A5 A5 A5
IP66/NEMA 4X A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous
(3x525–550 V) [A]
2.6 2.9 4.1 5.2 - 6.4 9.5 11.5
Intermittent
(3x525–550 V) [A]
2.9 3.2 4.5 5.7 - 7.0 10.5 12.7
Continuous
(3x525–600 V) [A]
2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Intermittent
(3x525–600 V) [A]
2.6 3.0 4.3 5.4 - 6.7 9.9 12.1
Continuous kVA
(525 V AC) [kVA]
2.5 2.8 3.9 5.0 - 6.1 9.0 11.0
Continuous kVA
(575 V AC) [kVA]
2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Max. input current
Continuous
(3x525–600 V) [A]
2.4 2.7 4.1 5.2 - 5.8 8.6 10.4
Intermittent
(3x525–600 V) [A]
2.7 3.0 4.5 5.7 - 6.4 9.5 11.5
Additional specifications
Estim. power loss at rated max. load
[W] 4)
50 65 92 122 - 145 195 261
IP20 max. cable cross-section (line
power, motor, brake and load
sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55, IP 66 max. cable cross-section
(line power, motor, brake and load
sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
Max. cable cross-section with
disconnect
6, 4, 4 (12, 12, 12)
Line power disconnect switch
included:
4/12
Weight IP20 (lbs [kg]) 14.33 [6.5] 14.33 [6.5] 14.33 [6.5] 14.33 [6.5] - 14.33 [6.5] 14.55 [6.6] 14.55 [6.6]
Weight IP21/55 (lbs [kg])
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76
[13.5]
29.76 [13.5] 29.76 [13.5] 31.31 [14.2]
31.31
[14.2]
Efficiency
4)
0.97 0.97 0.97 0.97 - 0.97 0.97 0.97
Table 10.6 Line Power Supply 3x525–600 V AC – Normal overload 110% for 1 minute
5)
With brake and load sharing 95/4/0
Specifications Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 81
