Danfoss VLT Midi Drive FC 280 Design Guide

Coil 0 1
33 Control not ready Control ready
34 Frequency converter not
ready
Frequency converter ready
35 Coast stop Safety closed
36 No alarm Alarm
37 Not used Not used
38 Not used Not used
39 Not used Not used
40 No warning Warning
41 Not at reference At reference
42 Hand mode Auto mode
43 Out of frequency range In frequency range
44 Stopped Running
45 Not used Not used
46 No voltage warning Voltage warning
47 Not in current limit Current limit
48 No thermal warning Thermal warning
Table 5.17 Frequency Converter Status Word (FC Prole)
Bus
address
Bus
register
1)
PLC
register
Content Access Description
0 1 40001 Reserved
–
Reserved for legacy frequency converters VLT
®
5000 and
VLT
®
2800.
1 2 40002 Reserved
–
Reserved for legacy frequency converters VLT
®
5000 and
VLT
®
2800.
2 3 40003 Reserved
–
Reserved for legacy frequency converters VLT
®
5000 and
VLT
®
2800.
3 4 40004 Free – –
4 5 40005 Free – –
5 6 40006 Modbus conguration Read/Write TCP only. Reserved for Modbus TCP
(parameter 12-28 Store Data Values and
parameter 12-29 Store Always - stored in, for example,
EEPROM).
6 7 40007 Last fault code Read only Fault code received from parameter database, refer to
WHAT 38295 for details.
7 8 40008 Last error register Read only Address of register with which last error occurred, refer
to WHAT 38296 for details.
8 9 40009 Index pointer Read/Write Subindex of parameter to be accessed. Refer to WHAT
38297 for details.
9 10 40010 Parameter 0-01 Language Dependent on
parameter
access
Parameter 0-01 Language (Modbus register = 10
parameter number)
20 bytes space reserved for parameter in Modbus map.
19 20 40020 Parameter 0-02 Motor Speed
Unit
Dependent on
parameter
access
Parameter 0-02 Motor Speed Unit
20 bytes space reserved for parameter in Modbus map.
29 30 40030 Parameter 0-03 Regional
Settings
Dependent on
parameter
access
Parameter 0-03 Regional Settings
20 bytes space reserved for parameter in Modbus map.
Table 5.18 Address/Registers
1) Value written in the Modbus RTU telegram must be 1 or less than the register number. For example, Read Modbus Register 1 by writing value 0
in the telegram.
RS485 Installation and Set-... Design Guide
MG07B102 Danfoss A/S © 03/2016 All rights reserved. 63
5 5
