Danfoss VLT Midi Drive FC 280 Design Guide

1 Introduction
1.1 Purpose of the Design Guide
This design guide is intended for project and systems
engineers, design consultants, and application and product
specialists. Technical information is provided to understand
the capabilities of the frequency converter for integration
into motor control and monitoring systems. Details
concerning operation, requirements, and recommendations
for system integration are described. Information is
provided for input power characteristics, output for motor
control, and ambient operating conditions for the
frequency converter.
Also included are:
•
Safety features.
•
Fault condition monitoring.
•
Operational status reporting.
•
Serial communication capabilities.
•
Programmable options and features.
Design details such as site requirements, cables, fuses,
control wiring, the size and weight of units, and other
critical information necessary to plan for system integration
are also provided.
Reviewing the detailed product information in the design
stage enables developing a well-conceived system with
optimal functionality and
eciency.
VLT
®
is a registered trademark.
1.2
Additional Resources
Resources available to understand operations and
programming of the frequency converter:
•
VLT® Midi Drive FC 280 Operating Guide, provides
information about the installation, commissioning,
application and maintenance of the frequency
converter.
•
VLT® Midi Drive FC 280 Programming Guide,
provides information on how to program and
includes complete parameter descriptions.
Supplementary publications and manuals are available
from Danfoss. See vlt-drives.danfoss.com/Support/Technical-
Documentation/ for listings.
1.3
Denitions
1.3.1 Frequency Converter
Coast
The motor shaft is in free mode. No torque on the motor.
I
VLT,MAX
Maximum output current.
I
VLT,N
Rated output current supplied by the frequency converter.
U
VLT,MAX
Maximum output voltage.
1.3.2 Input
Control commands
Start and stop the connected motor with LCP and digital
inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in
group 2.
Group 1 Precise stop, coast and reset stop, precise stop
and coast stop, quick stop, DC braking, stop, and
[OFF].
Group 2 Start, pulse start, reversing, start reversing, jog,
and freeze output.
Table 1.1 Function Groups
1.3.3 Motor
Motor running
Torque generated on the output shaft and speed from
0 RPM to maximum speed on the motor.
f
JOG
Motor frequency when the jog function is activated (via
digital terminals).
f
M
Motor frequency.
f
MAX
Maximum motor frequency.
f
MIN
Minimum motor frequency.
f
M,N
Rated motor frequency (nameplate data).
I
M
Motor current (actual).
I
M,N
Nominal motor current (nameplate data).
Introduction
VLT
®
Midi Drive FC 280
6 Danfoss A/S © 03/2016 All rights reserved. MG07B102
11
