DS2100N REFERENCE MANUAL
100
10
10 TECHNICAL FEATURES
ELECTRICAL FEATURES DS2100N-XXX0 DS2100N-XXX4
Input Power
Supply Voltage 10 to 30 Vdc
Power consumption max. 0.3 to 0.1 A; 3 W 0.5 to 0.17 A; 5 W
Serial Interfaces
Main Serial Interface Sw programmable: RS232; RS485 FD and HD
Baudrate 1200 - 115200
Auxiliary RS232
Baudrate 1200 - 115200
ID-NET™ RS485 Half-duplex
Baudrate Up to 1 MBaud
Inputs
Input 1 (External Trigger), Input 2 Optocoupled, polarity insensitive
Voltage 10 to 30 Vdc
Current Consumption 12 mA max.
Minimum Pulse Duration 5 ms.
Outputs
Output 1, Output 2 Optocoupled
V
CE
30 Vdc max.
Collector Current 40 mA continuous max.; 130 mA pulsed max.
V
CE saturation
1V max. at 10 mA
Power Dissipation
80 mW max. at 45 C (ambient temperature)
OPTICAL FEATURES
Light Source Semiconductor laser diode
Wave Length In the range 630 to 680 nm
Safety Class Class 2 - EN 60825-1; CDRH
READING FEATURES (Note 1)
Scan Rate (software program.) (500 to 800 scans/sec) (800 to 1000 scans/sec)
Aperture Angle 50°
Maximum Reading Distance
Maximum Resolution
See reading diagrams
ENVIRONMENTAL FEATURES
Operating Temperature (Note 2)
0° to +45 C (+32° to +113 °F)
Storage Temperature
-20° to +70 C (-4° to +158 °F)
Humidity max. 90% non condensing
Vibration Resistance 14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6 2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance 30g; 6 ms;
EN 60068-2-29 5000 shocks on each axis
Shock Resistance 30g; 11 ms;
EN 60068-2-27 3 shocks on each axis
Protection Class – EN 60529 IP65
PHYSICAL FEATURES
Mechanical Dimensions 68 x 84 x 34 mm (2.7 x 3.3 x 1.3 in)
Weight 330 g (11.6 oz.)
Note 1: Further details given in par. 7.3.
Note 2: If the reader is used in high temperature environments (over 40 C), use of the Beam Shutter is advised (see the
Genius™ configuration program) and/or a thermally conductive support (such as the metal bracket provided).
