Datalogic DS2100N User Manual

READING FEATURES
85
7
The decoder will be able to read the label with a tilt angle between
+  max and -  max as shown in the following figure:
Conveyor
Laser Beam
No Read
No Read
-

+

0°
O
K
O
K
O
K
O
K
O
K
No Read
Figure 104 – Reading Zones with  Max
NOTE
While tilt angles of 45° can be obtained, DS2100N scanners are not
designed to create omni-directional reading stations using two scanners in
an X-pattern.
